Description:

Whether you need to scan printed bar codes on paper labels or mobile bar codes on the screen of a mobile phone, with the DS9208, you’ll be ready. You get the versatility to scan any 1D or 2D bar code — from the printed labels in retail that identify product and pricing at the register to mobile coupons, mobile gift and loyalty cards, boarding passes and even theater tickets. And the DS9208 provides all the features you need to keep your workers productive: industry-leading scanning speed; true point-and-shoot scanning simplicity — no need to align bar code and scanner; and hands-free and handheld flexibility.

Specifications:

Dimensions : 5.512 in. H x 3.232 in. W x 3.150 in. D

   14.0 cm H x 8.21 cm W x 8.0 cm D

Weight: 9.5 oz./269 g

Voltage and Current: Idle- 5 ± 10% VDC @ 150ma average

   Scanning- 5 ± 10% VDC @ 230ma average

Color: Midnight Black​

Performance Characteristics

Light Source: Aiming pattern- single dot, 625nm LED

Illumination: 630nm LEDs

Imager Field of View: 46° Horizontal x 29.5° Vertical

Roll: 360°

Pitch: ± 65°

Yaw: ± 60°

Print Contrast: 25% minimum reflective difference

Swipe Speed (Vertical Read Rate): Up to 90 in./2.3 m per second

Graphics Format Support: Images can be exported as Bitmap, JPEG or TIFF

Image Transfer Speed: USB 2.0- Up to 12 Megabits/second

   RS-232- Up to 115 kb/second

Image Transfer Time: Typical USB application is ~0.2 seconds with a compressed JPEG of 100kb

Image Quality: 120 PPI on a 4 x 6 in./10.2 x 15.2 cm document @ 4.7 in./11.9 cm

Interfaces Supported: USB, RS-232, RS-485 (IBM 46xx Protocols), Keyboard Wedge

User Environment

Operating Temp.: 32° F to 104° F / 0° to 40° C

Drop Specs: Withstands multiple 5 ft./1.5 m drops to concrete

Humidity: 5% to 85% RH (non-condensing)

Ambient Light Immunity: Immune to natural and artificial ambient light (i.e. sunlight, incandescent, fluorescent,mercury vapor, sodium vapor)

Electronic Article Surveillance: Compatible with Checkpoint EAS deactivation systems

Accessories: Wall mount bracket; locking mount bracket
